QUALITY AND PROPERTIES

• High-grade acrylic quality
• Fast drying time
• Very good coverage
• Colour exact
• Excellent adhesion to several materials
• Long-lasting shine
• Good corrosion protection
• Good flow, smooth surface
• Ideally suited to spot welding
• Weatherproof, lightfast, UV resistant
• Scratch, shock and impact proof

PHYSICAL AND CHEMICAL DATA

• Basis of the binder: acrylic
• Colour: diverse
• Smell: solvent
• Degree of gloss: (at measurement angle 60° acc. to DIN 67530):
  glossy: 80 gloss units
  satin mat: 30-35 gloss units
  mat: 5-10 gloss units
• Efficiency:
  Depending on consistence and color of the ground:
  12 ml for small spots
  400 ml are sufficient for approx. 1.0 - 2.0 m²
• Drying time (at 20°C, 50% relative air humidity):
  12 ml:
  Dust-dry: after approx. 15 minutes
  Dry to touch: after approx. 60 minutes
  400 ml:
  Dust-dry: after approx. 10 minutes
  Dry to touch: after approx. 30 minutes
  Hard-dry: after approx. 2 hours
  Polishable: after approx. 24 hours
  The drying time depends on surrounding temperature, air humidity and thickness of the applied coat.
• Temperature resistance: up to 80°C
• Storage stability:
  Aerosols: 10 years, touch-up pencils: 5 years, if appropriate
  storage provided (=10°-25°C, relative air humidity of max.
  60%)
• Size:
  touch-up pencils 12 ml,
  aerosol cans, maximum nominal volume 400 ml

INSTRUCTION MANUEL

Before use, carefully read and observe the warning texts on the label!

Pre-treatment of surface:

• The surface should be clean, dry and free of grease.
• Sand old paintwork and coated parts first.
• Pre prime.
• Once dry, sand with 600-grit sandpaper.

Painting:

• The surface should be clean, dry and free of grease.
• Bring can to room temperature.
• Operating temperature 15 to 25°C.
• Shake can for 2 minutes before use.
• Test on inconspicuous area.
• Keep a spraying distance of ca. 25-30 cm.
• Apply several thin layers.
• Shake can from time to time during use.
• Do not spray on surfaces coated with synthetic resins!

TIPS FOR SPRAY PAINTING

Protect the object and the surrounding area from spray mist. When painting small areas it is recommended that a piece of card is used as a mask, with a hole cut in it slightly larger than the area to be sprayed. The mask should be held 1 to 2 cm from the surface. With this method, the mainly part of the spray mist is brought under control. It recommends to mask parts not to be lacquered, to protect the surrounding against the spray mist.

The aerosol can should have room temperature.

Temperature should range between +10°C and +25°C, max. air humidity 60 %.

Store in a dry place. Protect from direct sunlight and other sources of heat. Use only during dry weather, in places protected from the wind, and in well-ventilated rooms. Follow the warning texts on the labels!

ORDER INFORMATIONS

Color	Product	Bundle	Art.No.
	HG Klarlack 400	400 ml	07242
	HG RAL 1001 beige 400	400 ml	07068
	HG RAL 1002 sandgelb 400	400 ml	07067
	HG RAL 1003 signalgelb 400	400 ml	07069
	HG RAL 1004 goldgelb 400	400 ml	07072
	HG RAL 1005 honiggelb 400	400 ml	07073
	HG RAL 1006 maisgelb 400	400 ml	07075
	HG RAL 1007 narzissengelb 400	400 ml	07076
	HG RAL 1011 braunbeige 400	400 ml	07054
	HG RAL 1012 zitronengelb 400	400 ml	07055
	HG RAL 1013 perlweiss 400	400 ml	07056
	HG RAL 1014 elfenbein 400	400 ml	07057
	HG RAL 1015 hellelfenbein 400	400 ml	07062
	HG RAL 1016 schwefelgelb 400	400 ml	07003
	HG RAL 1017 safrangelb 400	400 ml	07064
	HG RAL 1018 zinkgelb 400	400 ml	07063
	HG RAL 1019 graubeige 400	400 ml	07065
	HG RAL 1021 rapsgelb 400	400 ml	07074
	HG RAL 1023 verkehrsgelb 400	400 ml	07071
	HG RAL 1028 melonengelb 400	400 ml	07077
	HG RAL 1032 ginstergelb 400	400 ml	07060
	HG RAL 1033 dahliengelb 400	400 ml	07061
	HG RAL 2000 signalorange 400	400 ml	07078
	HG RAL 2001 rotorange 400	400 ml	07081
	HG RAL 2002 blutorange 400	400 ml	07086
	HG RAL 2003 pastellorange 400	400 ml	07079
	HG RAL 2004 reinorange 400	400 ml	07007
	HG RAL 2008 hellrotorange 400	400 ml	07085
	HG RAL 2009 verk.orange 400	400 ml	07082
	HG RAL 2011 orange 400	400 ml	07080
	HG RAL 3000 feuerrot 400	400 ml	07090
	HG RAL 3001 signalrot 400	400 ml	07102
	HG RAL 3002 karminrot 400	400 ml	07096
	HG RAL 3003 rubinrot 400	400 ml	07100
	HG RAL 3004 purpurrot 400	400 ml	07106
	HG RAL 3005 weinrot 400	400 ml	07108
	HG RAL 3007 schwarzrot 400	400 ml	07103
	HG RAL 3009 oxidrot 400	400 ml	07104
	HG RAL 3011 braunrot 400	400 ml	07171
	HG RAL 3012 beigerot 400	400 ml	07087
	HG RAL 3014 altrosa 400	400 ml	07089
	HG RAL 3015 hellrosa 400	400 ml	07091
	HG RAL 3020 verkehrsrot 400	400 ml	07088
	HG RAL 3027 himbeerrot 400	400 ml	07092
	HG RAL 4001 rotlila 400	400 ml	07115
	HG RAL 4002 rotviolett 400	400 ml	07117
	HG RAL 4003 erikaviolett 400	400 ml	07114
	HG RAL 4004 bord.violett 400	400 ml	07122
	HG RAL 4005 blaulila 400	400 ml	07116
	HG RAL 4006 verk.purpur 400	400 ml	07112
	HG RAL 4007 purpurviolett 400	400 ml	07125
	HG RAL 4010 telemagenta 400	400 ml	07132
	HG RAL 5000 violettblau 400	400 ml	07008
	HG RAL 5001 grünblau 400	400 ml	07000
	HG RAL 5002 ultramarinblau 400	400 ml	07006
	HG RAL 5003 saphirblau 400	400 ml	07001
	HG RAL 5004 schwarzblau 400	400 ml	07133
	HG RAL 5005 signalblau 400	400 ml	07134
	HG RAL 5007 brillantblau 400	400 ml	07016
	HG RAL 5008 graublau 400	400 ml	07168
	HG RAL 5009 azurblau 400	400 ml	07135
	HG RAL 5010 enzianblau 400	400 ml	07004
	HG RAL 5011 stahlblau 400	400 ml	07005
	HG RAL 5012 lichtblau 400	400 ml	07014
	HG RAL 5013 kobaltblau 400	400 ml	07002
	HG RAL 5014 taubenblau 400	400 ml	07136
	HG RAL 5015 himmelblau 400	400 ml	07012
	HG RAL 5017 verkehrsblau 400	400 ml	07009
	HG RAL 5018 türkisblau 400	400 ml	07118
	HG RAL 5019 capriblau 400	400 ml	07017
	HG RAL 5021 wasserblau 400	400 ml	07137
	HG RAL 5022 nachtblau 400	400 ml	07138
	HG RAL 5024 pastellblau 400	400 ml	07139
	HG RAL 6000 patinagrün 400	400 ml	07010
	HG RAL 6001 smaragdgrün 400	400 ml	07119
	HG RAL 6002 laubgrün 400	400 ml	07121
	HG RAL 6003 olivgrün 400	400 ml	07140
	HG RAL 6004 blaugrün 400	400 ml	07141
	HG RAL 6005 moosgrün 400	400 ml	07128
	HG RAL 6009 tannengrün 400	400 ml	07123
	HG RAL 6010 grasgrün 400	400 ml	07126
	HG RAL 6011 resedagrün 400	400 ml	07124
	HG RAL 6012 schwarzgrün 400	400 ml	07011
	HG RAL 6014 gelbolive 400	400 ml	07142
	HG RAL 6016 türkisgrün 400	400 ml	07013
	HG RAL 6017 maigrün 400	400 ml	07143
	HG RAL 6018 gelbgrün 400	400 ml	07127
	HG RAL 6019 weissgrün 400	400 ml	07129
	HG RAL 6021 blassgrün 400	400 ml	07131
	HG RAL 6024 verkehrsgrün 400	400 ml	07120
	HG RAL 6026 opalgrün 400	400 ml	07144
	HG RAL 6027 lichtgrün 400	400 ml	07130
	HG RAL 6029 minzgrün 400	400 ml	07145
	HG RAL 6032 signalgrün 400	400 ml	07169
	HG RAL 7000 fehgrau 400	400 ml	07146
	HG RAL 7001 silbergrau 400	400 ml	07026
	HG RAL 7004 signalgrau 400	400 ml	07015
	HG RAL 7005 mausgrau 400	400 ml	07167
	HG RAL 7006 beigegrau 400	400 ml	07147
	HG RAL 7011 grau 400	400 ml	07019
	HG RAL 7012 basaltgrau 400	400 ml	07018
	HG RAL 7015 schiefergrau 400	400 ml	07148
	HG RAL 7016 anthrazitgrau 400	400 ml	07020
	HG RAL 7021 schwarzgrau 400	400 ml	07149
	HG RAL 7022 umbragrau 400	400 ml	07025
	HG RAL 7023 betongrau 400	400 ml	07150
	HG RAL 7024 graphitgrau 400	400 ml	07151
	HG RAL 7030 steingrau 400	400 ml	07030
	HG RAL 7031 blaugrau 400	400 ml	07022
	HG RAL 7032 kieselgrau 400	400 ml	07032
	HG RAL 7035 lichtgrau 400	400 ml	07034
	HG RAL 7036 platingrau 400	400 ml	07023
	HG RAL 7037 staubgrau 400	400 ml	07024
	HG RAL 7038 achatgrau 400	400 ml	07152
	HG RAL 7039 quarzgrau 400	400 ml	07039
	HG RAL 7040 fenstergrau 400	400 ml	07153
	HG RAL 7042 verk.grau "A" 400	400 ml	07028
	HG RAL 7043 verk.grau "B" 400	400 ml	07027
	HG RAL 7044 seidengrau 400	400 ml	07029
	HG RAL 8001 ockerbraun 400	400 ml	07154
	HG RAL 8002 signalbraun 400	400 ml	07170
	HG RAL 8003 lehmbraun 400	400 ml	07155
	HG RAL 8004 kupferbraun 400	400 ml	07109
	HG RAL 8007 rehbraun 400	400 ml	07111
	HG RAL 8011 nussbraun 400	400 ml	07113
	HG RAL 8012 rotbraun 400	400 ml	07031
	HG RAL 8014 sepiabraun 400	400 ml	07033
	HG RAL 8016 mahagonibraun 400	400 ml	07156
	HG RAL 8017 schokobraun 400	400 ml	07110
	HG RAL 8019 graubraun 400	400 ml	07035
	HG RAL 8028 terrabraun 400	400 ml	07157
	HG RAL 9001 cremeweiss 400	400 ml	07045
	HG RAL 9002 grauweiss 400	400 ml	07046
	HG RAL 9003 signalweiss 400	400 ml	07042
	HG RAL 9005 tiefschwarz 400	400 ml	07236
	HG RAL 9007 graualu. met. 400	400 ml	07216
	HG RAL 9010 reinweiss 400	400 ml	07040
	HG RAL 9011 graphitschwarz 400	400 ml	07158
	HG RAL 9016 verkehrsweiss 400	400 ml	07037
	HG RAL 9018 papyrusweiss 400	400 ml	07036
	MATT RAL 9005 tiefschwarz 400	400 ml	07238
	MATT RAL 9017 verk.schwarz 400	400 ml	07159
	Motip RAL 1013 perlweiß 12	12 ml	907056
	Motip RAL 1015 hellelfenbe. 12	12 ml	907062
	Motip RAL 1018 zinkgelb 12	12 ml	907063
	Motip RAL 1021 rapsgelb 12	12 ml	907074
	Motip RAL 3000 feuerrot 12	12 ml	907090
	Motip RAL 3001 signalrot 12	12 ml	907102
	Motip RAL 3002 karminrot 12	12 ml	907096
	Motip RAL 3003 rubinrot 12	12 ml	907100
	Motip RAL 3020 verkehrsrot 12	12 ml	907088
	Motip RAL 5002 ultram.blau 12	12 ml	907006
	Motip RAL 5003 saphirblau 12	12 ml	907001
	Motip RAL 5010 enzianblau 12	12 ml	907004
	Motip RAL 5012 lichtblau 12	12 ml	907014
	Motip RAL 5015 himmelblau 12	12 ml	907012
	Motip RAL 5017 verkehrsblau 12	12 ml	907009
	Motip RAL 6005 moosgrün 12	12 ml	907128
	Motip RAL 6009 tannengrün 12	12 ml	907123
	Motip RAL 6011 resedagrün 12	12 ml	907124
	Motip RAL 6018 gelbgrün 12	12 ml	907127
	Motip RAL 7001 silbergrau 12	12 ml	907026
	Motip RAL 7011 eisengrau 12	12 ml	907019
	Motip RAL 7016 anthraz.grau 12	12 ml	907020
	Motip RAL 7021 schwarzgrau 12	12 ml	907149
	Motip RAL 7031 blaugrau 12	12 ml	907022
	Motip RAL 7032 kieselgrau 12	12 ml	907032
	Motip RAL 7035 lichtgrau 12	12 ml	907034
	Motip RAL 7037 staubgrau 12	12 ml	907024
	Motip RAL 8017 schokobraun 12	12 ml	907110
	Motip RAL 8019 graubraun 12	12 ml	907035
	Motip RAL 9001 cremeweiß 12	12 ml	907045
	Motip RAL 9002 grauweiß 12	12 ml	907046
	Motip RAL 9003 signalweiß 12	12 ml	907042
	Motip RAL 9005 tiefschwarz 12	12 ml	907236
	Motip RAL 9006 silber 12	12 ml	907224
	Motip RAL 9007 graualumini. 12	12 ml	907216
	Motip schwarz matt 12	12 ml	907238
	SM RAL 9005 tiefschwarz 400	400 ml	07164
	SM RAL 9006 weissalu. met. 400	400 ml	07224
	SM RAL 9010 reinweiß 400	400 ml	07166

ENVIRONMENT AND LABELLING

Environmentally compatible: MOTIP DUPLI is committed to apply formulations without restricted or critical ingredients and to achieve best possible performance. The caps and packagings are made of recyclable material.

Disposal: Please mind the residue inside the containers. Completely emptied containers can be used for recycling. If cans are not emptied, they should be disposed off as "special refuse".

Labelling: All products of MOTIP DUPLI comply with the current status of their labelling regulations. Classification and distinction takes place by the presently legal form of the Globally Harmonized System of Classification and Labelling of Chemicals (GHS) or rather by CLP 1272/2008/EG regulations. Our safety data sheets comply with the current form of REACH 1907/2006/EG, article 31 und appendix II,
